Motor Magnetic Assemblies
Custom BLDC, PMSM, and stepper rotor assemblies. 100% flux tested, production-ready precision components.
Complete Magnetic Rotor Assemblies, Ready to Install
Precision Manufacturing Process
Technical Specifications
| Parameter | Capability Range |
|---|---|
| Magnet Material | Sintered NdFeB, SmCo, Ferrite, Bonded NdFeB |
| Max Diameter | 350 mm |
| Min Diameter | 2 mm |
| Shaft Concentricity | ≤ 0.02 mm (TIR) |
| Bond Method | Structural Epoxy, Press-Fit, Overmolding |
| Pole Count | 2 to 128 Poles |
| Flux Uniformity | ± 1.5% |
| Test Coverage | 100% Flux Mapping & Torque Testing |
Physical Specifications
| Component | Standard Materials |
|---|---|
| Rotor Hub / Back-Iron | 1010/1018 Steel, Stainless 416, Aluminum 6061 |
| Sleeving / Retention | Carbon Fiber, Stainless 304, Inconel 718 |
| Surface Treatment | Nickel, Epoxy Coating, Passivation, Zinc |
Applications
BLDC Hub Motors
High-torque direct drive rotors for electric mobility.
PMSM Servo Rotors
Precision motion control for industrial robotics.
Drone & UAV Motors
Ultra-lightweight high-speed rotors for flight systems.
EPS Automotive
Reliable power steering motor assemblies.
Pump Rotors
Sealed magnetic couplings for leak-proof fluid handling.
Washing Machines
Direct drive drum motor assemblies for home appliances.
Why Elite Magnets?
One-Stop Assembly
We handle machining, magnets, and assembly in-house.
100% Tested
Every rotor is flux mapped for performance verification.
Design Support
FEA simulation and DFM consulting for your motor design.
Factory Direct
Direct communication with engineers and competitive pricing.
Frequently Asked Questions
Do you supply shaft machining?
Yes, we provide full CNC machining for shafts and back-irons to ensure perfect fit and concentricity.
Can you magnetize after assembly?
Yes, post-assembly magnetization ensures higher flux density and better pole-to-pole consistency.
What adhesive systems do you use?
We use high-temperature structural epoxies (up to 200°C) tailored to your specific environment.
What concentricity tolerance can you hold?
Our standard is ≤0.02mm TIR, but we can achieve tighter tolerances depending on the design.
Do you provide FEA support?
Yes, we offer magnetic field simulation and FEA analysis to optimize your rotor’s performance.
Ready to Start Your Project?
Send us your drawings or specifications for a technical review and quote.
